Dingli
Home > New Equipment > Dingli
GTWY9.5-1300 (8m) Mobile Vertical Lifts
Name
GTWY9.5-1300 (8m) Mobile Vertical Lifts
Introdution
Model:GTWY9.5-1300
Work Height:9.5 m
Raised Platform Height:7.5 m
Lowered Platform Height:1.99 m
Overall Width:0.75 m
Overall Length:1.3 m
Weight (AC):430 kg
Weight (DC):453 kg
Ground Clearance:0.055 m
GTWY11-1300 (9m) Mobile Vertical Lifts
Name
GTWY11-1300 (9m) Mobile Vertical Lifts
Introdution
Model:GTWY11-1300
Work Height:110m
Raised Platform Height:9 m
Lowered Platform Height:1.99 m
Overall Width:0.75 m
Overall Length:1.34 m
Weight (AC):450 kg
Weight (DC):472 kg
Ground Clearance:0.055 m
GTWY12.5-1300 (11m) Mobile Vertical Lifts
Name
GTWY12.5-1300 (11m) Mobile Vertical Lifts
Introdution
Model:GTWY12.5-1300
Work Height:12.5 m
Raised Platform Height:10.5 m
Lowered Platform Height:2.35 m
Overall Width:0.75 m
Overall Length:1.53 m
Weight (AC):530 kg
Weight (DC):553 kg
Ground Clearance:0.055 m
GTWY14-1300 (12m) Mobile Vertical Lifts
Name
GTWY14-1300 (12m) Mobile Vertical Lifts
Introdution
Model:GTWY14-1300
Work Height:14 m
Raised Platform Height:12 m
Lowered Platform Height:2.77 m
Overall Width:0.75 m
Overall Length:1.53 m
Weight (AC):559 kg
Weight (DC):588 kg
Ground Clearance:0.055 m
GTWY9.5-2100 (8m) Mobile Vertical Lifts
Name
GTWY9.5-2100 (8m) Mobile Vertical Lifts
Introdution
新貨到
Model:GTWY9.5-2100
Work Height:9.5 m
Raised Platform Height:7.5 m
Overall Height(Stowed):1.99 m
Overall Width(Stowed):0.81 m
Overall Length(Stowed):1.56 m
Weight (AC):630 kg
Weight (DC):690 kg
Ground Clearance:0.055 m
GTWY11-2100 (9m) Mobile Vertical Lifts
Name
GTWY11-2100 (9m) Mobile Vertical Lifts
Introdution
新貨到
Model:GTWY11-2100
Work Height:11 m
Raised Platform Height:9 m
Overall Height(Stowed):1.99 m
Overall Width(Stowed):0.81 m
Overall Length(Stowed):1.56 m
Weight (AC):780 kg
Weight (DC):840 kg
Ground Clearance:0.055 m
GTWY12.5-2100 (10m) Mobile Vertical Lifts
Name
GTWY12.5-2100 (10m) Mobile Vertical Lifts
Introdution
新貨到
Model:GTWY12.5-2100
Work Height:12.5m
Raised Platform Height:10.50 m
Overall Height(Stowed):1.99 m
Overall Width(Stowed):0.81 m
Overall Length(Stowed):1.70 m
Weight (AC):820 kg
Weight (DC):880 kg
Ground Clearance:0.055 m
GTWY14-2100 (12m) Mobile Vertical Lifts
Name
GTWY14-2100 (12m) Mobile Vertical Lifts
Introdution
新貨到
Model:GTWY14-2100
Work Height:14 m
Raised Platform Height:12 m
Overall Height(Stowed):1.99 m
Overall Width(Stowed):0.81 m
Overall Length(Stowed):1.70 m
Weight (AC):1020 kg
Weight (DC):1080 kg
Ground Clearance:0.055 m
